Keychron C1 Pro QMK/VIA Wired Mechanical Keyboard
Keychron C1 Pro QMK/VIA Wired Mechanical Keyboard - White Backlight / K Pro Red Switch is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Please drop your email on "Notify Me When Available" if the product model is out of stock.
Keychron C1 Pro QMK/VIA Wired Mechanical Keyboard has included keycaps for both Windows and macOS.
The only difference between version 1 and version 2 is the chip they use.
C1 Pro Version 1 (C1P-A, C1P-B, C1P-H): STM32L432KB
C1 Pro Version 2 (C1P-K, C1P-L, C1P-M): STM32F402RC
Keychron C1 Pro QMK/VIA Wired Mechanical Keyboard
Keychron C1 Pro
The C1 Pro is a wired mechanical keyboard with a classic TKL (80%) layout and many premium features like QMK/VIA support, PBT keycaps, a 1000 Hz polling rate, etc., which provides endless possibilities and a comfortable typing experience!
Program C1 Pro with QMK & VIA
With full QMK and VIA support, you can easily program and remap each key on the keyboard. The open-source firmware means endless possibilities for keyboard layouts, shortcuts, backlight effects, and more.
Get the keymap working on VIA
Since the VIA code for the K8 Pro is still awaiting approval from Github, it is not automatically recognized yet. Please download the keymap JSON file below. Connect your keyboard and device with the provided cable, and toggle the switch to cable mode. Open VIA, click on the "Show Design tab" on the "Settings" tab. Drag the JSON file into the “Design” tab on VIA to get the K8 Pro keymap working on VIA.
Get the C1 Pro keymap working on VIA
Since the VIA code for the C1 Pro is still awaiting approval from Github, it is not yet automatically recognized. Please download the appropriate keymap JSON file below, open VIA, turn on "Show Design tab" on "Settings" tab, and drag the JSON file into the “Design” tab on VIA to get the C1 Pro keymap working on VIA.
C1 Pro Version 1: C1P-A, C1P-B, C1P-H
C1 Pro Version 2: C1P-K, C1P-L, C1P-M
An Epic Core Inside The Keyboard
A powerful ultra-low-power ARM architecture MCU equipped with 128K Flash will provide more flexibility for developers. The polling rate is 1000 Hz right out of the box, which makes the latency hardly noticeable even in competitive games.
OEM Profile Double-Shot PBT Keycaps
Engineered with double-shot keycap set on White and RGB Backlight versions, the PBT keycaps will provide excellent oil resistance, enhance the type feel, and prevent the legends from fading out.
Suitable For All Devices
The C1 Pro has a system toggle and additional customized keycaps for Windows and macOS systems. And you can even configure different keymaps for Mac and Windows devices, while VIA software is compatible with macOS, Windows, and Linux.
Check high-res keycap layout and size here.
Hot-Swappable
The hot-swappable sockets are mounted on the PCB, so you can install or change the switches without soldering (for hot-swappable version only). The PCB supports both 3-pin and 5-pin MX mechanical switches.
South-facing RGB Lights
The south-facing RGB LED designs to better illuminate the keyboard backlight from the typist’s angle with the premium non-shine-through PBT keycaps installed. The backlight is also free from interference when the users install Cherry-profile alternative keycaps on the keyboard. Also, it comes with 22+ types of RGB light in different styles (flashing, breathing, static red, etc.) to match your mood.
Pre-lubed Keychron K Pro Switch
By optimizing the switch mold, the K Pro switch wobbles less than a standard mechanical switch and feels smoother on each hit. Plus, the factory pre-lubed process on all the K Pro switches (exclude the clicky ones), no doubt this will ensure the best smoothness at your fingertips when typing.
Ergonomic Support
Three levels of adjustable typing angle (4.8º, 8.5º & 10.7º) and curved OEM-profile keycaps are all working together to provide long-lasting ergonomic support for your wrist.
What's in the box?
| Width | 129.3 mm |
|---|---|
| Length | 355.5 mm |
| Front Height | 17 mm (without keycaps) |
| Back Height | 28 mm (without keycaps) |
| Feet Height | 2 mm |
| Angle | 4.8° / 8.5° / 10.7° |
| Weight | 700 ± 10 g |
| Body Material | ABS Plastic |
| Polling Rate | 1000 Hz |
| Mount Style | Tray Mount Design |
| Keycaps | OEM profile double-shot PBT keycaps, not shine-through |
|---|---|
| MCU | Version 1: Ultra-low-power ARM Cortex-M4 32-bit STM32L432KB
Version 2: High-performance ARM Cortex-M4 32-bit STM32F402RC |
| Switches | Keychron K Pro |
| Backlight | South-facing RGB LED |
| Switch Support | Hot-swappable (5 pin & 3 pin) |
| Stabs | Plate-mounted stabs |
| Connectivity | Type-C |
| Cable | Type-C cable + Type-A to Type-C adapter |
| Operating Environment | -10℃ to 50℃ |
Learn more about the Keychron C1 Pro such as the shortcuts, assembling guide, factory reset, and more in the FAQ section.
